Upgrade Options
| Window and light option - Requires a full 3/4Npt fitting to welded into the tank through the back of the tank for the light to be mounted and wires run, a control box, with an “off and on” switch, a custom made 3/4” thick Borsilicate glass (Pyrex glass) assembly to be screwed into a 4” flanged fitting to be welded into the door of the tank |
 |
| Legs with Casters, and Levelers - This upgrade is used when the tank is to be moved or transported, and the short stand is not enough to raise the tank to the level of the operator |
 |
| Vacuum Casting Port - Use this when the operation requires filling the molds inside the tank under vacuum, then will allow the tank to seal off when the static mix tube is withdrawn and pressure is applied to the tank. All done without moving mold, requires a fitting to be welded through the tank, and our standard gate is installed |
 |
| Digital Forced Air Heating System - Unit is self contained and will work in most 24”dia X 48”long tanks setting on support rails spaced 8” apart. System requires 120V single phase,20amp and will produce 125degrees F, also requires two fittings welded into the back and side of tank for wiring, and temp probe |
 |
|
|
|
